No Need for a
Lot of Instruction to find
a sweet spot but some new concepts
to understand what is happening. |
The Tattanātor is a device that enables Tattoo
Artists to easily and quickly find the best speed and force
quickly without physically altering their machine. The
Tattanator can "dial-in" different combinations of speed and
force that a given coil machine is capable of, as
constructed and adjusted at that moment. It does this
by separating the on/off electronics from the frame by means
of electronic rather than mechanical switching (the contact point/spring for on and off)
which is made
obsolete.
Speed is user-selectable by turning the left dial from 60
to 120 hits (Hz) per second, measured in Hertz (Hz). The right
dial controls the duty cycle (the % of the on + off cycle) from 10 to 65%.
The longer it is on during each cycle the more power the
machine has. The contact screw position determines the upper stroke
height: the longer the stroke the faster the needle travels.
The interaction of speed, duty cycle, stroke length, and
the mechanical properties of the tattoo machine determine
the stroke-hit force.
Pre-Tattanātor mechanically-switched tattoo machines were very difficult to
tune because you could only use voltage increase or decrease
and then adjust the tattoo machine itself each time you made
a change to speed. The interaction between speed, duty
cycle, and stroke length is all you have with regular power
supplies. It is obvious ly better to be able to
control speed and force separately.
The
Tattanātor
is intuitive and requires virtually no instruction. It is
quick, easy and enlightening.
Teachers and
Promising Artists
can be liberated from the up-hill battle
with the mechanics of the coil machine
during initial
learning.
The
Tattanātor
makes the Science of Tattoo Machine
Possible.
This was never possible before. |
Besides being able to set and
tune a coil machine by dialing the right settings, it is a
learning tool because everything is now objective,
measurable, quantifiable ( expressed in numbers ). In other
words, The
Tattanātor has created the Science of Tattoo
Machine Performance. For the first time everything can be
scientifically compared in numbers: machines, coils,
springs, how frames effect performance. For builders and
designers a new generation of designs is now possible
because the frame is independent of the electronics, the
contact screw now only controls stroke length, the "contact"
function as well as the capacitor are obsolete.
Could be
A New Period of Discovery. |
The
contribution is Benchmarking. Now the
job of Tattoo Artists and Machine Designers and Builders is
to develop the actual standards and determine the speed and
forces necessary for the best, most effective tattooing.
Unimax has a long
history of contributions to the technology of tattoo.
Being chosen to develop and market the
Tattanātor
has been an Honor.
New life for an Old
Technology. |
