Swashdrive Gen VI, Generation 6
SWASHDRIVE™® by CRAIG WYETH - AUSTRALIA
Unmistakably - The Most Advanced Technology
Black Polyamide $399.00
Polyamide with Binding Posts for Clip Cord, #4A423.
Polyamide with RCA Jack, #4A425
3.6 Oz. 103 Grams
316 Cast Stainless Steel $469.00
Stainless Steel with Binding Posts for Clip Cord, #4A421
Stainless Steel with RCA Jack, #4A422
5.5 Oz. 156 Grams
Order cords separately.
| Characteristics of the Generation 6 Swashdrive: |
|
www.slavetotheneedle.com
 |
|
Looking down at the Swash from above:
The motor runs in a CLOCKWISE direction >.
RCA type connector wiring:
Positive (+) (Red wire) connected to center terminal
Negative (-) (Black wire) connected to outer shield
Binding Posts for Spring type CLIP CORD
connector wiring:
Positive (+) (Red wire) connected to Top Post
Negative (-) (Black wire) connected to Bottom Post
If your Gen 6 is not running switch the clip cord around.
The Swashplate
The swashplate mechanism that drives the needle action is
a very efficient means
to convert the rotational motion of
the electric motor
to the reciprocating motion
of the needle
producing
an approximate advantage of 15:1.
The swashplate delivers a sine wave motion - constant
needle velocity -
throughout the cycle producing a
smooth non-stopping continuous motion
as compared to the
stop and start of conventional crank, cam (2-dimension) and
coils.
Only the swashplate can make use of all
3-dimension axes to create
the natural fluid cyclic
reciprocating action that produces
a constant "brush-like"
artistry feel experienced by fine art painting.
A small precision bearing has been added in the anvil
area to remove
the "rock-over" that was so hard on grommets
and nipples.
The Anvil area is now part of the C shape pivot clip.
Included are 4 replacement "C-Clips" with every machine.
RoHS Compliant
Voltage: 1.0 ~ 12 Volts
Amps: 0.08 ~ 0.35 Amps
- Speed: Cycles Per Second
- at 6.0 Volts - 50 CPS
- at 9.0 Volts - 100 CPS
- at 12 Volts - 150 CPS
Motor: 4.5 Watt
Custom Design
Swiss Maxon Motor
the motor has a life expectancy
of approx. 20,000 hours.
www.swashdrive.com.au
Power supplies
The Gen 6 Swashdrive will run on almost any power supply, but we strongly recommend the use of a quality bridge rectified Dual lab, for the clean DC . Cheap single knob supplies with heaps of ripple & noise will reducing motor life somewhat.
Tested & Endorsed power
supplies for this machine.
Genuine GW Instek lab
Isotech lab (Model IPS303DD,
RS Components
part # 3256004)
The power supply should have no more than
Ripple & Noise ≥1.0mVrms ( 5Hz~1MHz )
(rating current <3A )
Tested and endorsed:
Genuine GW Instek, Isotech Lab
Set Power Supply
before starting Swash
Gen VI:
This is important on START-UP to deliver full amps
and then
settle to what the machine draws at desired voltage.
-
SET at ZERO Volts
-
SET at FULL AMPS
- Hit foot pedal and use Voltage knob to increase speed.
From www.swashdrive.com.au
Warranty
The Swashdrive Tattoo machine has a Six month warranty from date of purchase. To which Swashdrive Developments will repair any manufacturing fault of the machine free of charge. However disassembly of electric motor from the main machine frame, or excess voltage from single knob power supplies wrecking electric motor will invalidate warranty. Proof of date of purchase must be provided for a warranty claim.
Disclaimer
Swashdrive Developments warrantees the manufacturing quality of the Swashdrive Tattoo machine. But under no circumstances is Swashdrive Developments in any way liable for any injury, infection or quality of any tattoo or of any person that Swashdrive Tattoo machine is used on. That is the sole responsibility & liability of the Artist / Owner of this Swashdrive Tattoo machine.
We apologize to tattoo people
looking for detailed info on the Swashdrive. We had to remove a lot
of content from
www.swashdrive.com.au because PARASITE SUPPLIERS were using the
Tech Help info to clone a
GOLD COLOR KNOCKOFF of our hard earned invention. Don't be
fooled.
The Swashdrive is a high tech device with quality components!
