Description & Control Panel
It's intuitive to operate.
Set Speed, find Duty % setting,
Use Contact Screw to limit Up-Swing.
Understanding the science...Not required.

The Tattanator is like cooking.
Control the amount of each ingredient.
 Traditional power supplies can only set the
Amount of Voltage. Duty cycle cannot be set.
 Voltage (Only)
That's the only ingredient it can directly change.
The screens look interesting but
everything changes only as Voltage changes.

The UP Part shown below in Visual
is the Duty Cycle % (the ON)
which represents machine hitting force.
The down part is in the OFF stage.

UP takes time and OFF takes time.
The two together repeating make a cycle.


The screens below are real.
The Duty Cycle % was changed.
The longer it is ON the stronger the force.
That's basically it to get going.
Speed 91 Hits/Sec
Coils Energized
40% of Each Cycle
Speed 91 Hits/Sec
Coils Energized
30% of Each Cycle

Stronger

Softer

(Freq.) Speed is the same in both settings.
But the Duty Cycle (Hitting) was reduced.

Motor-driven machines have to invent
physical work-arounds to PARTIALLY compensate
for the hard-hitting no-give limitation of the design.

Coil machines are
Easy to convert to and off a Tattanator
Enhanced performance.
